Expand Memory Under Windows -This Is How To Do It?

If the computer becomes slow under load, it is often due to the dynamic memory. But you can easily upgrade it.

Main memory, also known as RAM, is still a typical bottleneck today: Despite all the advances in memory management, the RAM will eventually be full, and the computer will fall back on flipbook performance. See how to upgrade your PC here.

Where is the problem?

Is memory even the problem? In practice, it is usually expressed as follows: A lot of programs are already open, you open another one and hey presto – the computer hardly reacts at all. Even moving the mouse pointer is like a slideshow; switching, let alone operating, no longer works.

In this situation, you should call up the Windows Task Manager, which will take forever again and often works best using the key combination [CTRL] + [ALT] + [DEL], and check the available memory there. If it is almost 100 per cent, the problem has been identified.

Typical causes of this kind of trouble: web browsers, especially Google Chrome , with lots of open tabs, virtual machines or video editing. If you regularly use one or two virtual machines and Chrome with 20 tabs, you can no longer cope with even 16 gigabytes of RAM. The operating system uses the high-speed RAM (Random Access Memory) to store data that is currently required temporarily. If the RAM is full, it is transferred to the hard disk – and in contrast to the main memory, it is unbearably slow.

All optimization does not help. You only have two options: Either you change the way you work – which is generally a bad idea. Or you can expand the RAM. And do not worry, this is trivial: These are simply small breadboards that you plug into the mainboard. You don’t have to set anything, configure anything, or do anything. However, you must first find out which components you need and how many slots you have access to.

Also Read: A Complete Guide On How To Recover Permanently Deleted Files From Windows And Mac

Which RAM modules?

First of all, you should clarify which building blocks you need. You are essentially confronted with two values: the type (DDR2, DDR3, DDR4) and the speed, for example, “DDR3 1600″. The design must match your previous RAM modules or the mainboard; the rate should be the same for all built-in modules but does not have to be – however, the slowest module slows down faster ones. After all: DDR2, DDR3 and DDR4 are built differently – if the bolt physically fits into the mainboard, it is also a suitable one.

If you still have it, you can have a look at the manual for your motherboard. It works much better with a hardware analysis tool like SiSoft Sandra Lite. Start the software, go to the ” Mainboard ” area and look for the entries in the list that begin with ” Memory Module “. Here you can see which components are installed – in the picture below, for example, components of the type “DDR3 1600”.

But you still need some information: How many slots for RAM bars are there on your mainboard, and how many of them are occupied? Sandra lists all memory modules individually; that’s easy. You can also see the exact name of the mainboard here and can use it to search online and look for slots at the manufacturer.

But there is also a much easier way: Open the calculator and take a look! You can easily recognize the latch because there are at least two slots right next to each other, and at least one is equipped with a latch that is approximately 13 centimetres long and 3 centimetres high. There are also things with lighting in gaming computers, but you will probably already know if you have something like this.

Assuming you still have a free slot, you can buy a structurally designed latch of any size and add it. If you only have two occupied seats, you can choose to swap both or just one. The disadvantage of the second variant: Your old RAM module will tend to be slower than your new acquisition.

In that case, you will flush a little money into the toilet either way: Either the paid performance of the new bar is lost, or a RAM module goes to the garbage (of course, adequately disposed of in the electronic waste ). You will get the best results if you use two or more identical bars. Two 8 GB bars can also be addressed better than one 16 GB bar. This is why RAM modules are often offered as a two-pack.

Also Read: How To Share Your Dropbox Folder?

Upgrade RAM

The actual upgrade is now much easier than in advance: If not already done, open the computer and look for the memory bar. You can see small clips that lock the building block in place to the left and right of the sockets. Loosen these clamps and, if necessary, carefully pull the module straight up and out.

Now insert the new module straight into the socket, also from above. The notch in the contact strip of the latch is not in the middle, so you cannot install the latch the wrong way round. As soon as the new latch is in place, secure it again with the small clips to the left and right of the slot. The whole thing works without pressure or fiddling – if not, check whether the bar is seated correctly! And that’s it – close, start-up, enjoy the faster system!

Two more tips for handling the building blocks: The things are not made of porcelain or sugar, but a little caution can’t hurt. On the one hand, you should generally not touch the chips directly but always grab the bar from the sides. On the other hand, it doesn’t hurt to ground yourself beforehand to not damage the chips with static electricity.

It is sufficient, for example, to take hold of an unpainted piece of heating pipe. Of course, an antistatic workstation with a rubber mat underneath would be ideal. Still, I said: These things are not made of sugar – if you are not shuffling across the carpet with the bar in your hand on socks, RAM bars have a good chance of survival and last but not least: Of course, you should completely disconnect the computer from the power supply before switching!
